home >  Products > Transformers  >   Audio Transformers  >  SP-4

Image is for reference.Plz contact us to get the real picture

  • Part Number
  • SP-4
  • Manufacturers

  • Triad Magnetics

  • Description
  • TRANSF 200K CT/1K CT AUDIO
  • Lead Free Status / RoHS Status
  • ROHS3 Compliant
  • Data sheet

  • SP-4.pdf

Total :

$0.723
Submit a quote on large quantities or your Target Price.

Target Price(USD)

Qty

REMARK

SP-4 is available at our website. We only sale New&Original Part and offer 1 year warranty time. If you would like to know more about the products or apply more better price, please contact us click the Online Chat or send a quote to us.

In Stock

6730 pcs

Refrence Price
(In US Dollars)

  • 1 pcs

  • $ 0.723

Requote Quote

  • Product Parameter
  • Product Datasheets
  • Packaging
  • Shipping
  • Payment

  • Part Number

    SP-4

  • Manufacturers

    Triad Magnetics

  • Description

    TRANSF 200K CT/1K CT AUDIO

  • Mfr

    Triad Magnetics

  • Series

    Red-Spec

  • Package

    Bulk

  • Product Status

    Active

  • Turns Ratio - Primary:Secondary:14.1

    1

  • Impedance - Primary (Ohms)

    200kCT

  • Impedance - Secondary (Ohms)

    1kCT

  • DC Resistance (DCR) - Primary

    5.3kOhm

  • DC Resistance (DCR) - Secondary

    100Ohm

  • Transformer Type

    Audio Coupling

  • Frequency Range

    300Hz ~ 100kHz

  • Frequency Response

    ±2dB

  • Voltage - Isolation

    1000VRMS @ 1 Second

  • Insertion Loss

    -

  • Return Loss

    -

  • Power Level

    10mW

  • Operating Temperature

    -40°C ~ 85°C

  • Approval Agency

    -

  • Mounting Type

    Through Hole

  • Size / Dimension

    0.410" L x 0.310" W (10.41mm x 7.87mm)

  • Height - Seated (Max)

    0.465" (11.80mm)

  • Termination Style

    PC Pin

  • Weight

    -
